Bucyrus HW300 SHM SHM51 Technical Manual BI616169 PDF

Bucyrus HW300 SHM SHM51 Technical Manual BI616169 PDF

Total Size of Files: 812 KB
Format of the File: PDF
File Language: English
Make: Caterpillar
Type of Machine: Highwall Miner
Type of Document: Technical Manual
Model Name: HW300 SHM SHM51 Highwall Miner
Highwall Miner HW300 SHM SHM51 Technical Manual BI616169
Part Number: BI616169
Number of Pages: 42 Pages

Detail Contents:
Blocking \ Latching Cylinders say “Changing when being raised
Blocking \ Latching Cylinders say “Changing when being lowered
CHM Level is not working properly
Buttons on the touch screen display #COM, Nothing will start
Cutter Head will not shear
Hot Oil
Main Breaker in the ECM is kicking when you start a motor
Main Breaker in the ECM will not start
Sump Problems
Power Head will not move backwards
Power Head will not move forwards
PTM I without Proportional Valve will not swing
PTM with Proportional Valve will not swing
PTM II Cradle will not move
PTM II Trolley will not move
Vertical Conveyor will not Swing
Troubleshooting Sump Problems
